INGENUITY
Advanced production equipment and manufacturing technology make Korig products stand the temper; Key parts of the implementation of global selection procurement, Korig will be able to create high-quality products for you to meet your individual needs.
Precision CNC fiber laser cutting machine
Our company's product production process has advanced and perfect crane manufacturing process and supporting equipment, tooling system, from steel pretreatment, blanking, welding, assembly, heat treatment, painting the entire process of product production
Digital vertical lathe
The digital vertical lathe (double column) DVT500 × 25/32 can meet the processing of rotating parts with a diameter of 5300mm and a height of 2250mm. Its processing performance is in good fit with the components of Korig Corporation's products, greatly ensuring processing quality and efficiency.
Heavy duty CNC floor milling machine bed
Korig has one heavy-duty CNC floor milling machine TK6926J, two TK6920A, and one TK6916A with the Spanish FAGOR8055 CNC system. It can meet the overall processing of various tonnage crane small frames, end beams, and crossbeams, as well as other large structural components such as balance beams, rotating hanging beams, crossbeams, and super large door seats for large gantry cranes
Large scale shadow data gantry milling machine
One CNC gantry milling machine XK2740 and two XK2420, with machining stroke ranges of 10000 × 4000x (300~1900) mm, 6000 × 2000 × 1200mm, and 5000 × 2000 × 1200mm respectively, are used for machining integral small frame, pulley beam, crossbeam, intermediate end beam, balance beam, etc.
Double gun gantry welding center
The company has multiple double gun gantry submerged arc welding machines for welding the outer longitudinal seams of main beams and end beam box type structural components. The welding of the main beams adopts the double wire welding method. It is the first in China to develop a crane arch parabolic mechanical weld seam tracking automated welding process equipment, achieving fully automated welding processes for crane curves and variable cross-sections
1250t press machine
12500KN four column hydraulic press, with a maximum stroke of 1200mm for the slider and a maximum distance of 2000mm from the slider to the worktable. The effective area of the worktable can reach 3200mm (approximately) 1600mm (front and back). Mainly used for the bending and shaping of medium thick steel plates, such as pre bending of steel plate rolling drums.
Heavy structural component annealing furnace
Stress relief annealing is mainly used to ensure the dimensional stability of welded structural components and prevent deformation due to long-term aging. Our company has a trolley type natural gas annealing furnace with a net furnace size (length X width X height) of 16000mm X6000mm X8000mm, which can meet the post weld stress relief annealing treatment of various large, medium and small welded structural components.
  • Plate pretreatment
  • laying-off
  • Assembly welding
  • Machining technology
  • Coating technology
Our company has 5 QXY3000 and QYX6930 steel plate and profile pretreatment production lines (including shot blasting, painting, and drying). After casting (spraying) the steel, in order to prevent rust, the primer should be sprayed immediately within the specified time after the pre-treatment is completed. The steel used for the main structural components such as bridge frames and trolley frames is pre treated before entering the production workshop.
  • Steel plate pretreatment production line
  • Steel plate pretreatment production line - uncoiling
  • Steel plate pretreatment production line - shot blasting
  • Coating of steel plate pretreatment production line
Our company has various cutting equipment and advanced cutting processes, adopting different cutting techniques and methods according to different needs. Our company has 18 precision plasma cutting machines of various models, 4 AG-600 CNC flame cutting machines, 3 15000W CNC laser cutting machines, etc. The main components are cut using fine plasma and CNC laser cutting, with cutting accuracy better than 1mm and sheet metal warping deformation less than 2mm.
  • Precision CNC fiber laser cutting machine
  • Plasma CNC cutting machine
  • CNC flame cutting machine
  • CNC bending
  • 1250t press machine
The welding process of the crane product adopts flexible digital electric permanent magnet lifting equipment and control system, which ensures high safety and reliability during lifting. To improve the quality of the welding process, combined with current 5G communication technology, robot welding technology is widely applied in components such as crane main beams, end beams, and trolleys, effectively improving welding efficiency and ensuring the overall manufacturing quality of the crane.
  • End beam welding robot workstation
  • Digital electric permanent magnet transportation
  • Double gun gantry welding center
  • Machine frame robot welding workstation
  • Main beam internal seam welding robot workstation
  • Automated flipping tool
Our company has various top domestic brands of CNC machining equipment and production lines, and has developed industry-specific machining processes. In addition to meeting the full mechanical processing capabilities of components, we also cooperate with self-made process equipment to achieve innovative breakthroughs in the overall machining of various structural components.
  • Large CNC gantry boring and milling machine
  • Large horizontal milling and boring machine
  • Imported MAZAK machining center
  • Imported NILES CNC gear grinding machine
  • Overall processing of bridge after welding
  • CNC lathe robot
  • CNC planer type milling and boring machine
  • CNC heavy-duty horizontal lathe
  • Digital vertical lathe
  • The overall processing of the car frame after welding
  • Overall heat treatment of small car frame
  • Heavy structural component annealing furnace
  • Heavy duty CNC floor milling and boring machine
Korig is the first in the lifting industry to apply automated coating for large structural components, constructing one robot coating line, two semi-automatic coating lines, and one sandblasting line. Carry out emission control from the source, process, and end, and achieve intelligent and green product coating. The intelligent coating production line can complete the main beam coating operation of a crane in 30 minutes, with more stable spraying quality and higher spraying precision, greatly improving the product coating quality.
  • Intelligent coating workshop
  • Intelligent coating production line
  • Intelligent coating production line
